Geforce 6100


754GT6-P

754GT6-P NVIDIA nForce 6100 GPU (C 51G ) + nForce 410 MCP (MCP 51G ) Chipset Support 64-bit AMD Sempron 64 processor Support HTT 800MHz Integrated 425MHz GeForce 6100 Graphics Single Channel DDR400 Memory DIMMs Support 2 Serial ATA2 Devices with RAID 0, 1 Support Hardware NV Firewall Ethernet LAN Supported ACбж97 8 Channel Audio CODEC CPU Vcore 7-Shift ATX Form Factor

64-bit AMD Athlon 64 Processor with HyperTransportTM Technology

AMD64, a revolutionary technology allowing the processor to run 32-bit applications at full speed while enabling a new generation of powerful 64-bit software applications. Hyper-TransportTM technology can increase overall system performance by removing I/O bottlenecks, increasing system bandwidth, and reducing system latency .



NVIDIA GeForce 6100 GPU (C 51G ) and nForceTM410 MCP (MCP 51G ) / The ultimate enthusiast platform

NVIDIA GeForceTM 6100 GPU (C 51G ) based Motherboards are indutry бж s first motherboards with Microsoft® DirectX® 9.0 Shader Model 3.0 capability. NVIDIA GeForce 6 Series GPUs deliver ultra-realistic effects and unmatched multimedia functionality for an incredible PC experience on popular games and multimedia applications. And nFoeceTM410 MCP (MCP 51G ) chipset implements the next-generation PCI-Express bus architecture and Serial ATA2 devices supported features for the scalability and flexibility of the expansionary abilities of the outstanding motherboards .



CPU Thermal Throttling / The Anti-superheated CPU protection Technology

To prevent the increasing heat from damaging of CPU while the activation of the Bi-turbo technology, the CPU Thermal Throttling Technology will make CPU be idling from 87.5% to 12.5% by manually preset CPU operating temperature from 40 вJ to 90 вJ . When the system senses the climbing operating temperature of CPU over the value preset, CPU Thermal Throttling Technology will narrow the operating bandwidth of CPU actively to low down the temperature to the value preset as the perfect protection system of hardware dynamic over-clocking technology .



Serial ATA2 with RAID

Serial ATA2 is an evolutionary replacement for the Parallel ATA physical storage interface. Users of the Serial ATA2 interface benefit from greater speed, simpler upgradeable storage devices and easier configuration. Integrated Serial ATA2 controller of high-speed data transfers at up to 300 MB/s for each port and optional available on different model is RAID 0, 1 and 0+1 support .



CPU Smart Fan / The Noise Restrained System

Itбжs never been a good idea to sacrifice the sound effects for gaining the performance you need. CPU Smart Fan Noise Restrained System is the answer to all the noise restrained needed high performance computing system, the system will automatically increase the fan speed when CPU operating loading is high, after the CPU is in normal operating condition, the system will low down the fan speed for the silent operating environment. The system can provide the much longer life cycle for both CPU and the system fans for game use and business requirements .



CPU Vcore 7-Shift / Shift_to the scalabilities and flexibilities The adjustable voltage for CPU Vcore can be upgraded in seven stages for the precisely hardware dynamic over-clocking of demanding computing performance .



Specification

Performance List The following performance data list is the testing result of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users (the different Hardware & Software configuration will result in different benchmark testing results.) Performance Test Report CPU:                     AMD K8 Athlon64 3200+ Support (Socket 754, 512k L2 cache)  DRAM:          KingMax MPTC220D-38HT 512MB DDR500 X 2 (1Gbyte) Memory VGA Card :         Onboard VGA share 64M(nForce 8.20+ VGA Driver8133) / GeForce6600GT 128M PCI-E VGA CARD (1024X768X32BIT Color) Hard Disk Driver: Seagate Barracude 7200.7 SATA150 BIOS:             Award Optimal default OS:                 Windows XP Professional (SERVICE PACK 2)          200/200  Single channel (C51G) 200/200  Single channel (GeForce6600GT) 3D Mark 2001SE 4118 18047 3D Mark 2003 1103 8163 3D Mark 2005 571 3516 AQUAMRK3 10149 (1119 / 5373) 53413 (7773 / 8529) PCMark2004 System / CPU / Memory 3311 / 3724 / 3179 3809 / 3731 / 3311 Graph / HDD 1121 / 4613 4238 / 4648 Content Creation Winstone 2004 30.3 31.2 Business Winstone 2004 23.2 23.5 Winbench 99 V2.0: Business/Hi-end Disk Winmark99 17200 / 40100 17200 / 41400 Business/Hi-end Graphic Winmark 646 / 1790 648 / 1800 SISMark 2004: SISMark Rating(Internet Content Creation / Office Productivity ) SISMark 2004 167 (174 / 161) 166 (173 / 159) 3D Creation / 2D Creation 169 / 201 169 / 200 / Web publication 156 153 Communication / Document Creation 177 / 173 171 / 174 / Data Analysis 137 136 SISOFT Sandra 2004 : 1.CPU Arithmetic Benchmark 2.Memory bandwidth Benchmark 3.CPU Multi-Media Benchmark 1.Dhrystone ALU MIPS 9226 3171 / 4106 Whetstone FPU iSSE2 FLOPS 3170 / 4105 2500 / 2500 2.Int/Float Buffered iSSE2 MB/S 2500 / 2500 19157 / 20601 3.Integer/Floating-Point SSE2 IT/S 19154 / 20595 47.38 / 29.51 UT2003 Benchmark (flyby/botmatch) 247.92 / 83.34 46.90 / 29.06 Quake3 DEMO1 / DEMO2 FPS N / A N / A DOOM3 FPS 6.6 87.9 Super Pi (1M) Second 46s

BIOS
Type Version size Description Date Download BIOS 05 512KB

Jetway has phased out this product.Please ask Jetway FAE for BIOS download when there is need.

2006-11-27

 Driver
Type Version size Description Date Download VGA   60M NF4 Geforce 6100 VGA Driver For VISTA 64 bit

os: Windows VISTA 64bit

2008-1-1 Download Link VGA   51M NF4 Geforce 6100 VGA Driver For VISTA 32bit

os: Windows VISTA 32bit

2008-1-1 Download Link VGA   36M NF4 Geforce 6100 VGA Driver For Windows XP 64

os: Windows XP 64bit

2008-1-1 Download Link VGA   21M NF4 Geforce 6100 VGA Driver

os: Windows 2000 , Windows XP 32 bit

2008-1-1 Download Link Sound   40M OnBoard ALC Codec Sound Driver

os: Windows 2000 , Windows XP , VISTA

2007-5-23 Download Link Chipset   85M NF4 Chipset Driver For VISTA

os: Windows VISTA 64bit

2007-4-10 Download Link Chipset   74.6M NF4 Chipset Driver For VISTA

os: Windows VISTA 32 bit

2007-4-10 Download Link Chipset   37M NF4 Chipset Driver For Windows XP 64

os: Windows XP 64bit

2006-4-4 Download Link Chipset   35M NF4 Chipset Driver

os: Windows 2000 , Windows XP 32 bit

2006-4-4 Download Link

Manual
Type Version size Description Date Download Manual   1.76 M/B For 64-bit AMD Socket 754 Processor 2006-4-19 Download Link

Utility
Type Version size Description Date Download Utilities 8.83 32KB BIOS Update Utilities 2006-7-31 Download Link
