RS480

A210GDMS-PRO

ATi RS480 Chipset,Support 64bit AMD Athlon64 939-Pin CPU Frequency 1000MHz Onboard ATI X300 base VGA Onboard 32M Hyper memory VGA display memory (A210GDAG PRO) 8 Channel Speaker DDR333/400 SDRAM Support On-board Giga LAN Support SATA150
Support 64 bit AMD Athlon64 939-pin FCPGA proccessor support CPU Frequency 1000MHZ
ATI RADEON EXPRESS 200 (RS480) North Bridge ,ULI M1573 South Bridge.
OnBoard ATI RADEON X300 Based VGA
Onboard 32M Hyper memory VGA display memory (A210GDAG Pro only)
OnBoard SATA Controller
OnBoard Giga LAN
Support 8-Channel Speaker
Support PCI-EXPRESS
Support DDR400 DDR SDRAM
PCбж99 Ready & PCбж99 Colorful I/O Ports Design
Support USB Controller & PS/2 Mouse , Standard IR (infrared) Function
Provide extra " three-wire" fans connectors
Frequency Magic Setting
PC Health Monitoring On Post Screen
Magic Install
BIOS Auto Detect CPU voltage
Y2K Compliant
ACPI Supporting For OS Directed Power Management Modem Ring remote wake up RTC alarm wake up Wake on LAN For OS Support software suspend & power off Support Power Button Ride (Instant off or Delay 4 second power off)  Specification Performance List                                   The following performance data list is the testing result of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users (the different Hardware & Software configuration will result in different benchmark testing results.) Performance Test Report CPU:                    AMD K8 Athlon 64 3400+ ( 512k L2 cache ) DRAM:                         TwinMOS hynix Hy5 du56822 CT 512M DDR400 X 2 (1Gbyte) Memory, VGA Card:        Onboard VGA share 64M (1024X768X32bit Color) Hard Disk Driver:   Seagate Barracude 7200.7 SATA150 BIOS:                      BIOS Load Optimal Default OS:                             Windows XP Professional (SERVICE PACK 2) 3D Mark 2001SE 6579 3D Mark 2003 1817 3D Mark 2005 735 AQUAMRK 3 14778 ( 1593 / 10258 )  PCMark2004  System / CPU / Memory 4083 / 4116 / 4994  Graph / HDD 1641 / 4550  Content Creation Winstone 2004 33.2  Business Winstone 2004 24.5  Winbench 99 V2.0:  Business/Hi-end Disk Winmark99 8780 / 20900  Business/Hi-end Graphic Winmark 981 / 2110 SISMark 2004 : SISMark Rating (Internet Content Creation / Office Productivity) SISMark 2004 182 ( 198 / 167 ) 3D Creation / 2D Creation 188 / 246 / Web publication 167 Communication / Document Creation 152 / 186 /Data Analysis 165 SISOFT Sandra 2005 :1.CPU Arithmetic Benchmark 2.Memory bandwidth Benchmark 3.CPU Multi-Media Benchmark 1.Dhrystone ALU MIPS 9397 Whetstone FPU iSSE2 FLOPS 3602 / 4677 2.Int/Float Buffered iSSE2 MB/S 5610 / 5556 3.Integer/Floating-Point iSSE2 IT/S 20920 / 22555 UT2003 Benchmark (flyby/botmatch) FPS 76.32 / 47.29 Quake3 DEMO1 / DEMO2 FPS 191.1 / 183.8 Return to Castle Wolfenstein FPS 86.6 Super Pi (1M) Second 40s CPU System / MEMORY / CPU Mhz

 BIOS
Type Version size Description Date Download BIOS   5M   2006-3-1 Download Link

Driver
Type Version size Description Date Download LAN   12M OnBboard Realtek PCI Lan Driver

os: Windows 98SE , 2000 , Windows XP , VISTA

2008-8-28 Download Link Sound   44M Onboard ALC HD Sound Driver

os: Windows 2000 , Windows XP , VISTA

2008-8-28 Download Link Sound   44M Onboard ALC HD Sound Driver

os: Windows 2000 , Windows XP , VISTA

2008-8-28 Download Link Chipset   2.4M Uli SATA Chipset Driver

os: Windows 2000 , Windows XP 32 bit

2006-4-4 Download Link VGA   44M ATI RS480 VGA Driver For XP64

os: Windows XP 64 bit

2006-4-4 Download Link VGA   23M ATI RS480 VGA Driver

os: Windows 2000 , Windows XP 32 bit

2006-4-4 Download Link

 Manual
Type Version size Description Date Download Manual   43.6M USER IS MANUAL M/B For Socket 939 AMD Athlon64 Processo 2006-3-9 Download Link

 Utility
Type Version size Description Date Download Utilities 8.83 32KB BIOS Update Utilities 2006-7-31 Download Link
