RS480

A210GDAG

ATi RS480 Chipset,Support 64bit AMD Athlon64 939-Pin CPU Frequency 1000MHz Onboard ATI X300 base VGA Onboard 32M Hyper memory VGA display memory (A210GDAG PRO) 8 Channel Speaker DDR333/400 SDRAM Support On-board Giga LAN Support SATA150
Support 64 bit AMD Athlon64 939-pin FCPGA processor support CPU Frequency 1000MHZ
ATI RADEON EXPRESS 200 (RS480) North Bridge ,ULI M1573 South Bridge.
OnBoard ATI RADEON X300 Based VGA
Onboard 32M Hyper memory VGA display memory (A210GDAG Pro only)
OnBoard SATA Controller
OnBoard Giga LAN
Support 8-Channel Speaker
Support PCI-EXPRESS
Support DDR400 DDR SDRAM
PCбж99 Ready & PCбж99 Colorful I/O Ports Design
Support USB Controller & PS/2 Mouse , Standard IR (infrared) Function
Provide extra " three-wire" fans connectors
Frequency Magic Setting
PC Health Monitoring On Post Screen
Magic Install
BIOS Auto Detect CPU voltage
Y2K Compliant
ACPI Supporting For OS Directed Power Management Modem Ring remote wake up RTC alarm wake up Wake on LAN For OS Support software suspend & power off Support Power Button Ride (Instant off or Delay 4 second power off)  Specification SPECIFICATION Processor 64bit AMD Athlon64 939-Pin package utilizes Flip-Chip Pin Grid Array package processor , Support CPU Frequency 1000MHz Chipset ATI RADEON EXPRESS 200 (RS480) North Bridge ULI M1573 South Bridge Jumpless Support Jumpless Function by BIOS SETUP Let Users More Easier to Change The Frequency Expansion Slot One PCI-EXPRESS * 16 Slot Two PCI-EXPRESS * 1 Slots Four 32 bit PCI Slots System Memory 4 x 184-pin DDR Dual Channel DDR Module Socket support DDR400 DDR SDRAM up to 4GB System memory. On Board IDE Support 2 X IDE Connectors for up to 4 IDE Drives Support PIO Mode 3 and Mode 4 and Bus Master IDE DMA, Mode 4 Timing for up to 16M Bytes/s Support UTRA DMA-133 Bus Master IDE, Provide faster transfer rate up to 133M Bytes/s Support LS-120 / ZIP Device On Board Serial ATA Support 4 Serial ATA Ports up to 150MB(Max) transfer rate Support RAID0,RAID1,RAID0+1 function On Board LAN Realtek 8110S PCI LAN Controller for operate 1G/100M/10M Base Fast Ethernt Support IEEE 802.3 Dual Channel DMA On Board 3D Audio ALC880 8-CH High Definition Audio Controller Support 8 channel Speaker On Board Ultra I/O 2 X Serial Ports (16550 Fast UART Compatible) 1 X Parallel Port (EPP and ECP capabilities) 1 X Floppy Disk Connector (Supports 2 Floppy Drivers) 1 X PS2 Mouse Connector 1 X Keybord Cnnector 2 X Three Wire FAN Connector (Include CPU FAN) 1 X LINE IN / LINE OUT / Microphone Connector 2 X Analog Audio CD Music line Connectors (different connector) On Board USB 8 X USB 2.0 Ports Connector Support USB Keyboard & USB Mouse Power Saving ACPI/APM Power Management Modem Ring remote wake up RTC Alarm Wake up Support Software Suspend & Power off Wake on LAN For OS Support Power Button Ride (Instant off or Delay 4 second power off) Power Supply Support 20-pin ATX power supply (ATX-PW) Support ATX12V Power Supply BIOS Award BIOS , Support Green function, Plug and Play Function 4MBit Flash ROM Dimension ATX Form Factor with 30.5cm X 24.5cm

BIOS
Type Version size Description Date Download BIOS       2006-3-3 Download Link
 Driver
Type Version size Description Date Download LAN   12M OnBboard Realtek PCI Lan Driver

os: Windows 98SE , 2000 , Windows XP , VISTA

2008-8-28 Download Link Sound   44M Onboard ALC HD Sound Driver

os: Windows 2000 , Windows XP , VISTA

2008-8-28 Download Link Sound   44M Onboard ALC HD Sound Driver

os: Windows 2000 , Windows XP , VISTA

2008-8-28 Download Link Chipset   2.4M Uli SATA Chipset Driver

os: Windows 2000 , Windows XP 32 bit

2006-4-4 Download Link VGA   44M ATI RS480 VGA Driver For XP64

os: Windows XP 64 bit

2006-4-4 Download Link VGA   23M ATI RS480 VGA Driver

os: Windows 2000 , Windows XP 32 bit

2006-4-4 Download Link

Manual
Type Version size Description Date Download Manual   43.6M M/B For Socket 939 AMD Athlon64 Processo 2006-4-13 Download Link
Utility
Type Version size Description Date Download Utilities 8.83 32KB BIOS Update Utilities 2006-7-31 Download Link
